Kyoritsu · AC/DC Clamp Meter
Kyoritsu KT 203 AC/DC Clamp Meter
Available on order
Price on Request
Send a Get Best Price request and we will reply with a quotation.
- GST Invoice
- Pan India Delivery
- Manufacturer Warranty
Prices are indicative. We confirm stock and send a proforma invoice, including freight, before payment.
Overview
The Kyoritsu KT 203 is a compact AC/DC clamp meter that measures both AC and DC current up to 400 A through a 30 mm jaw. DC current capability makes it useful on battery, UPS and solar DC circuits as well as AC loads.
It also measures AC and DC voltage to 600 V, resistance to 4000 Ω and continuity. It runs on two AAA cells and is rated IEC 61010-1 CAT III 300 V (current) / CAT II 600 V.
Key features
- AC and DC current 40 / 400 A (auto-ranging)
- 30 mm jaw
- AC and DC voltage to 600 V, resistance and continuity buzzer
- Runs on two AAA cells
- IEC 61010-1 CAT III 300 V (ACA) / CAT II 600 V
Specifications
| AC Current | |
|---|---|
| AC A | 40.00 / 400.0 A (auto-ranging); ±3.0% rdg ±8 dgt [50/60 Hz] (0–40.00 A), ±3.5% rdg ±6 dgt [50/60 Hz] (15.0–299.9 A), ±4.0% rdg ±6 dgt [50/60 Hz] (300.0–400.0 A) |
| DC Current | |
| DC A | 40.00 / 400.0 A (auto-ranging); ±3.0% rdg ±8 dgt (0–40.00 A), ±3.5% rdg ±6 dgt (15.0–299.9 A), ±4.0% rdg ±6 dgt (300.0–400.0 A) |
| Voltage | |
| AC V | 400.0 / 600 V (auto-ranging) ±2.0% rdg ±5 dgt (50/60 Hz) |
| DC V | 400.0 / 600 V (auto-ranging) ±1.5% rdg ±5 dgt |
| Resistance & Continuity | |
| Resistance | 400.0 / 4000 Ω (auto-ranging) ±2.0% rdg ±5 dgt |
| Continuity buzzer | Buzzer below 50 ±35 Ω |
| Jaw & Safety | |
| Conductor size | φ30 mm max. |
| Measurement category | IEC 61010-1 CAT III 300 V (ACA) / CAT II 600 V, pollution degree 2 |
| Standards | IEC 61010-2-032, IEC 61326-1 |
| General | |
| Power source | R03 (AAA, 1.5 V) × 2; approx. 35 hours continuous; auto power save approx. 10 minutes |
| Dimensions | 187 (L) × 68.5 (W) × 38.5 (D) mm |
| Weight | Approx. 200 g (including batteries) |
Specifications are taken from the manufacturer's published documentation and may change. Please verify the exact specification in the manufacturer's datasheet before relying on it for a critical application.
Applications
Suitable for applications such as:
- Electrical MaintenanceAC and DC current to 400 A plus voltage and continuity.
Accessories included
| Part no. | Item | Qty |
|---|---|---|
| 7066A | Test leads | 1 |
| R03 | AAA battery | 2 |
| – | Instruction manual | 1 |
Optional accessories (sold separately)
- 9105 – Carrying case
Safety standards
- IEC 61010-1 CAT III 300 V (ACA)
- IEC 61010-1 CAT II 600 V
- IEC 61010-2-032
- IEC 61326-1
What's in the box
- Kyoritsu KT 203 AC/DC Clamp Meter
- Test leads (7066A)
- 2 × AAA battery (R03)
- Instruction manual
Supplied with: Certificate of Conformity.
Datasheet and manual
Manufacturer information
The KT 203 is designed and manufactured by Kyoritsu Electrical Instruments Works, Ltd. (KEW), Japan. Industrial Supply Syndicate is an independent reseller; manufacturer warranty terms apply.
Buying guidance
The KT 203 suits light-duty AC and DC current checks up to 400 A. For higher current, a larger jaw or a CAT IV rating, look at the KEW 2055.
Frequently asked questions
What is the Kyoritsu KT 203 used for?
Small, handy 400 A AC/DC clamp meter with voltage, resistance and continuity functions.
What safety category is the Kyoritsu KT 203 rated for?
It is rated IEC 61010-1 CAT III 300 V (ACA) / CAT II 600 V, pollution degree 2, according to the manufacturer's specification.
What accessories are included with the Kyoritsu KT 203?
The standard package includes: Test leads (7066A); 2 × AAA battery (R03); Instruction manual.
