Kyoritsu · Pen Type Digital Multimeter
Kyoritsu KEW 1030 Pen Type Digital Multimeter
In stock
- In Stock – Kolkata Warehouse
- GST Invoice
- Pan India Delivery
- Manufacturer Warranty
Prices are indicative. We confirm stock and send a proforma invoice, including freight, before payment.
Overview
The Kyoritsu KEW 1030 is a pen-shaped digital multimeter that weighs about 100 g. It measures DC voltage to 600 V, AC voltage to 600 V, resistance to 40 MΩ, capacitance, frequency and duty cycle, and has a continuity buzzer and diode test.
A penlight lights up the test point and the LCD has a backlight, which helps inside panels and poorly lit spaces. The test lead winds into a compartment at the back of the meter. It runs on two LR44 button cells and is rated IEC 61010-1 CAT III 600 V.
Key features
- Pen-type body, approx. 100 g, with double moulding for grip
- Penlight illuminates the measuring point
- Backlit LCD
- Test lead stores in a rear compartment
- DC V, AC V, resistance, continuity, diode, capacitance, frequency and duty cycle
- Data hold button
- IEC 61010-1 CAT III 600 V
Specifications
| Voltage | |
|---|---|
| DC V | 400 mV / 4 / 40 / 400 / 600 V (5-range auto); ±0.8% rdg ±5 dgt (400 mV–400 V), ±1.0% rdg ±5 dgt (600 V) |
| AC V | 4 / 40 / 400 / 600 V (4-range auto); ±1.3% rdg ±5 dgt (4/40 V, 50/60 Hz), ±1.6% rdg ±5 dgt (400/600 V, 50/60 Hz) |
| Resistance & Continuity | |
| Resistance | 400 Ω / 4 / 40 / 400 kΩ / 4 / 40 MΩ (6-range auto); ±1.0% rdg ±5 dgt (400 Ω–4 MΩ), ±2.5% rdg ±5 dgt (40 MΩ) |
| Continuity buzzer | Buzzer at 120 Ω or less |
| Diode test | Test voltage approx. 0.3–1.5 V |
| Other Functions | |
| Capacitance | 50 / 500 nF / 5 / 50 / 100 µF (5-range auto); ±3.5% rdg ±10 dgt (50 nF), ±3.5% rdg ±5 dgt (500 nF–50 µF), ±4.5% rdg ±5 dgt (100 µF) |
| Frequency | 5 / 50 / 500 Hz / 5 / 50 / 200 kHz ±0.1% rdg ±5 dgt (input 1.5 V rms or more) |
| Duty cycle | 0.1–99.9% ±2.5% rdg ±5 dgt |
| Other | Data hold |
| Safety | |
| Measurement category | IEC 61010-1 CAT III 600 V |
| Standards | IEC 61010-031, IEC 61326-1 |
| General | |
| Power source | LR44 (SR44) 1.5 V × 2 |
| Dimensions | 190 (L) × 39 (W) × 31 (D) mm |
| Weight | Approx. 100 g (including batteries) |
Specifications are taken from the manufacturer's published documentation and may change. Please verify the exact specification in the manufacturer's datasheet before relying on it for a critical application.
Applications
Suitable for applications such as:
- Field Electrical TestingPen-type 100 g meter with penlight and backlit display.
- Electrical MaintenanceVoltage, resistance, continuity and capacitance checks; CAT III 600 V.
Accessories included
| Part no. | Item | Qty |
|---|---|---|
| 9130 | Carrying case | 1 |
| LR44 | Button cell | 2 |
| – | Instruction manual | 1 |
Optional accessories (sold separately)
- 9130 – Carrying case
Safety standards
- IEC 61010-1 CAT III 600 V
- IEC 61010-031
- IEC 61326-1
What's in the box
- Kyoritsu KEW 1030 Pen Type Digital Multimeter
- Carrying case (9130)
- 2 × Button cell (LR44)
- Instruction manual
Supplied with: Certificate of Conformity.
Datasheet and manual
Manufacturer information
The KEW 1030 is designed and manufactured by Kyoritsu Electrical Instruments Works, Ltd. (KEW), Japan. Industrial Supply Syndicate is an independent reseller; manufacturer warranty terms apply.
Buying guidance
The KEW 1030 is a good second meter for a tool pouch, or for technicians who mostly check voltage and continuity. It has no current ranges; use it with a clamp meter when you need current.
